Multi-Position – HE Series

View More Evaporator Coils
Overview

The HE Series premier evaporator coils match perfectly with any system, providing an upgrade over standard matched coils.

See Product Literature
Key Features
  • FlexCoil: Engineered for all refrigerants
  • Lower heights and variable widths for a perfect furnace fit
  • Cased, uncased, multi-position and upflow/ downflow configurations
  • Built-in plenum flanges with rounded corners for fast and safe installation
  • Front panel with only four screw access and non-captive refrigerant lines for fast and easy coil access
  • Available in copper or aluminum
  • Painted cabinet options for furnace color coordination
Specifications
  • Size: Available 1.5 – 5 tons
Literature
HE Series Products are Most Suited in the Following Regions
Nomenclature

This is an explanatory chart breaking down each component within your character string that identifies your product. Learn More

H G32 1 24 D 145 B 12 05 N
Cabinet Color
H = Embossed
A = Armstrong
G = ICP
J = Goodman/
Amana
N = Nordyne
P = Carrier/
Bryant/
Payne
R = Rheem/
Ruud
T = Trane/
American Standard
Y = York/
Luxaire/
Coleman
Slab No.
E&A = Copper slab
G = Aluminum slab
Refrigerant Type & Metering Device (Field Configurable)
1 = Piston1
A = R-45B Non-Bleed HP-A/C TXV
B = R-32 Non-Bleed HP-A/C TXV
C = R-454B Bleed HP-A/C TXV
Nominal MBTUH
Cabinet Depth
A = Uncased
C = 20.5"2
D = 21.0"
E = 21.5"
Width
Cased
140 = 14.0"
142 = 14.25"
145 = 14.5"
175 = 17.5"
210 = 21.0"
245 = 24.5"
255 = 25.5"
Uncased
130 = 13.0"
140 = 14.0"
155 = 15.5"
170 = 17.0"
200 = 20.0"
205 = 20.5"
235 = 23.5"
Cabinet Upper Notch
A = Uncased
B = 0.75"
(Standard)
Cabinet Height
00 = Uncased
12 = 12.5"
16 = 16.5"
18 = 18.5"
(up to 31.5")
Configuration
00 = Right-hand uncased
01 = Right-hand cased
04 = Left-hand uncased
05 = Left-hand cased
20 = Right-hand cased multi-position
22: Left-hand cased multi-position
Refrigerant Detection System (Field Configurable)
R = Included (Factory Installed)
N = Not Included (Field Installed)
